EC5645ETTTS-48.000MTR,日蝕有源晶振,2520晶體振蕩器

EC5645ETTTS-48.000MTR,日蝕有源晶振,2520晶體振蕩器EC5645ETTTS-48.000MTR,日蝕有源晶振,2520晶體振蕩器

產品簡介

EC5645ETTTS-48.000MTR,日蝕有源晶振,2520晶體振蕩器,從結構工藝來看,EC5645ETTTS-48.000MTR采用全密封金屬外殼封裝,相較于傳統陶瓷封裝,金屬外殼具備更優異的屏蔽性能,能有效隔絕外界電磁輻射與機械振動干擾,大幅降低信號失真風險,保障晶振長期穩定工作.內部搭載高精度石英晶體單元,經過Ecliptek獨家的精密切割與校準工藝處理,結合低噪聲振蕩電路設計,實現了低相位噪聲特性,在高頻工作狀態下仍能保持信號純凈度.同時,2520小型化封裝搭配標準化貼片引腳設計,完美適配自動化SMT貼裝工藝,提升生產效率的同時,減少人工組裝誤差,降低生產成本.

產品詳情


JLXNR-1

JLX-1

EC5645ETTTS-48.000MTR,日蝕有源晶振,2520晶體振蕩器

JLXNR-2

JLX-2

EC5645ETTTS-48.000MTR,日蝕有源晶振,2520晶體振蕩器

原廠型號Originalmodel： EC5645ETTTS-48.000M TR 品牌brand： Ecliptek晶振
Manufacturer品牌 Ecliptek晶振 OperatingTemperature溫度 -40°C ~ 85°C
Series型號 EC56 Current-Supply(Max) 8mA
Type類型 XO (Standard) PackageHeight高度 1.00mm
Frequency頻率 48 MHz Termination腳位 4 pad
輸出方式Output： LVCMOS PackageType封裝類型 4-SMD
Voltage-Supply電壓 3.3V Packaging包裝 TapeandReel
FrequencyStability頻率穩定度 ±50ppm 安裝方式Installation： Surfacemount
Size/Dimension尺寸 2.50mm x 2.00mm 最小包裝數MPQ： 3000

JLXNR-3

JLX-3

EC5645ETTTS-48.000MTR,日蝕有源晶振,2520晶體振蕩器

EC56

JLXNR-4

EC5645ETTTS-48.000MTR,日蝕有源晶振,2520晶體振蕩器

EC5625ETTTS-8.000M TR Ecliptek晶振 EC56 XO (Standard) 8 MHz LVCMOS 3.3V ±25ppm
EC3645ETTTS-8.000M TR Ecliptek晶振 EC36 XO (Standard) 8 MHz LVCMOS 3.3V ±50ppm
EC3625ETTTS-32.000M TR Ecliptek晶振 EC36 XO (Standard) 32 MHz LVCMOS 3.3V ±25ppm
EB13E2H2H-25.000M TR Ecliptek晶振 EB13E2 XO (Standard) 25 MHz CMOS 3.3V ±50ppm
EB13E2H2H-50.000M TR Ecliptek晶振 EB13E2 XO (Standard) 50 MHz CMOS 3.3V ±50ppm
EB13E2H2H-33.333M TR Ecliptek晶振 EB13E2 XO (Standard) 33.333 MHz CMOS 3.3V ±50ppm
EB13E2H2H-48.000M TR Ecliptek晶振 EB13E2 XO (Standard) 48 MHz CMOS 3.3V ±50ppm
EB13E2H2H-24.000M TR Ecliptek晶振 EB13E2 XO (Standard) 24 MHz CMOS 3.3V ±50ppm
EC5645ETTTS-24.000M TR Ecliptek晶振 EC56 XO (Standard) 24 MHz LVCMOS 3.3V ±50ppm
EC5645ETTTS-25.000M TR Ecliptek晶振 EC56 XO (Standard) 25 MHz LVCMOS 3.3V ±50ppm
EC2745ETTTS-25.000M TR Ecliptek晶振 EC27 XO (Standard) 25 MHz LVCMOS 2.5V ±50ppm
EC3645TS-25.000M TR Ecliptek晶振 EC36 XO (Standard) 25 MHz LVCMOS 3.3V ±50ppm
EC3645TTS-25.000M TR Ecliptek晶振 EC36 XO (Standard) 25 MHz LVCMOS 3.3V ±50ppm
EC3645ETTTS-12.000M TR Ecliptek晶振 EC36 XO (Standard) 12 MHz LVCMOS 3.3V ±50ppm
EC3625ETTTS-16.000M TR Ecliptek晶振 EC36 XO (Standard) 16 MHz LVCMOS 3.3V ±25ppm
EC3625ETTTS-27.000M TR Ecliptek晶振 EC36 XO (Standard) 27 MHz LVCMOS 3.3V ±25ppm
EC3645ETTTS-25.000M TR Ecliptek晶振 EC36 XO (Standard) 25 MHz LVCMOS 3.3V ±50ppm
EC3625ETTTS-25.000M TR Ecliptek晶振 EC36 XO (Standard) 25 MHz LVCMOS 3.3V ±25ppm
EC2645TS-25.000M TR Ecliptek晶振 EC26 XO (Standard) 25 MHz LVCMOS 3.3V ±50ppm
EC2645TTS-33.000M TR Ecliptek晶振 EC26 XO (Standard) 33 MHz LVCMOS 3.3V ±50ppm
EC2600TS-40.000M TR Ecliptek晶振 EC26 XO (Standard) 40 MHz LVCMOS 3.3V ±100ppm
EC2620TS-25.000M TR Ecliptek晶振 EC26 XO (Standard) 25 MHz LVCMOS 3.3V ±20ppm
EC2645ETTS-33.333M TR Ecliptek晶振 EC26 XO (Standard) 33.333 MHz CMOS 3.3V ±50ppm
EQRD13K2J-156.250M TR Ecliptek晶振 EQRD XO (Standard) 156.25 MHz LVPECL 3.3V ±50ppm
EC5625ETTTS-4.000M TR Ecliptek晶振 EC56 XO (Standard) 4 MHz LVCMOS 3.3V ±25ppm
EC3625TTS-27.000M TR Ecliptek晶振 EC36 XO (Standard) 27 MHz LVCMOS 3.3V ±25ppm
EC5945ETTS-26.000M TR Ecliptek晶振 EC56 XO (Standard) 26 MHz CMOS 1.8V ±50ppm
EB13E2E2H-25.000M TR Ecliptek晶振 EB13E2 XO (Standard) 25 MHz CMOS 3.3V ±25ppm
EB13E2E2H-50.000M TR Ecliptek晶振 EB13E2 XO (Standard) 50 MHz CMOS 3.3V ±25ppm
EB13E2D2H-40.000M TR Ecliptek晶振 EB13E2 XO (Standard) 40 MHz CMOS 3.3V ±50ppm
EB13E2J2H-50.000M TR Ecliptek晶振 EB13E2 XO (Standard) 50 MHz CMOS 3.3V ±25ppm
EB13E2H2H-16.000M TR Ecliptek晶振 EB13E2 XO (Standard) 16 MHz CMOS 3.3V ±50ppm
EC5625ETTTS-12.000M TR Ecliptek晶振 EC56 XO (Standard) 12 MHz LVCMOS 3.3V ±25ppm
EC5645ETTTS-32.000M TR Ecliptek晶振 EC56 XO (Standard) 32 MHz LVCMOS 3.3V ±50ppm
EC2745TTS-25.000M TR Ecliptek晶振 EC27 XO (Standard) 25 MHz LVCMOS 2.5V ±50ppm
EC3625ETTTS-10.000M TR Ecliptek晶振 EC36 XO (Standard) 10 MHz LVCMOS 3.3V ±25ppm
EC3645ETTS-25.000M TR Ecliptek晶振 EC36 XO (Standard) 25 MHz LVCMOS 3.3V ±50ppm
EC3645TS-50.000M TR Ecliptek晶振 EC36 XO (Standard) 50 MHz LVCMOS 3.3V ±50ppm
EC2620TS-12.000M TR Ecliptek晶振 EC26 XO (Standard) 12 MHz CMOS 3.3V ±20ppm
EC2620TS-50.000M TR Ecliptek晶振 EC26 XO (Standard) 50 MHz LVCMOS 3.3V ±20ppm
EV32C6A3A1-24.576M TR Ecliptek晶振 EV32 XO (Standard) 24.576 MHz CMOS 3.3V ±50ppm
EB13E2E2H-16.000M TR Ecliptek晶振 EB13E2 XO (Standard) 16 MHz CMOS 3.3V ±25ppm
EC3600ETTS-18.432M TR Ecliptek晶振 EC36 XO (Standard) 18.432 MHz LVCMOS 3.3V ±100ppm
EB13E2H2H-10.000M TR Ecliptek晶振 EB13E2 XO (Standard) 10 MHz CMOS 3.3V ±50ppm
EB13E2H2H-27.000M TR Ecliptek晶振 EB13E2 XO (Standard) 27 MHz CMOS 3.3V ±50ppm
EB13E2H2H-20.000M TR Ecliptek晶振 EB13E2 XO (Standard) 20 MHz CMOS 3.3V ±50ppm
EB13E2H2H-12.000M TR Ecliptek晶振 EB13E2 XO (Standard) 12 MHz CMOS 3.3V ±50ppm
EC3645ETTTS-24.000M TR Ecliptek晶振 EC36 XO (Standard) 24 MHz LVCMOS 3.3V ±50ppm
EB15E2C2H-40.000M TR Ecliptek晶振 EB15E2 XO (Standard) 40 MHz LVCMOS 2.5V ±100ppm
EC2600TS-66.000M TR Ecliptek晶振 EC26 XO (Standard) 66 MHz LVCMOS 3.3V ±100ppm
EC5645ETTTS-27.000M TR Ecliptek晶振 EC56 XO (Standard) 27 MHz LVCMOS 3.3V ±50ppm
EC5645ETTTS-30.000M TR Ecliptek晶振 EC56 XO (Standard) 30 MHz LVCMOS 3.3V ±50ppm
EC5645ETTTS-48.000M TR Ecliptek晶振 EC56 XO (Standard) 48 MHz LVCMOS 3.3V ±50ppm
EB13E2H2H-8.000M TR Ecliptek晶振 EB13E2 XO (Standard) 8 MHz CMOS 3.3V ±50ppm
EB13E2E2H-48.000M TR Ecliptek晶振 EB13E2 XO (Standard) 48 MHz CMOS 3.3V ±25ppm
EB13E2E2H-8.000M TR Ecliptek晶振 EB13E2 XO (Standard) 8 MHz CMOS 3.3V ±25ppm
EB13E2H2H-24.576M TR Ecliptek晶振 EB13E2 XO (Standard) 24.576 MHz CMOS 3.3V ±50ppm
EC5625ETTTS-10.000M TR Ecliptek晶振 EC56 XO (Standard) 10 MHz LVCMOS 3.3V ±25ppm
EB13E2J2H-25.000M TR Ecliptek晶振 EB13E2 XO (Standard) 25 MHz CMOS 3.3V ±25ppm
EB13E2H2H-14.7456M TR Ecliptek晶振 EB13E2 XO (Standard) 14.7456 MHz CMOS 3.3V ±50ppm
