藍牙模塊專用晶振SG3225CAN編碼X1G005961002215

返回列表 來源：金洛鑫 瀏覽：- 發布日期：2022-09-30 15:08:15【大 中 小】
分享到：

晶振在藍牙模塊中無處不在，藍牙模塊是藍牙適配器的半成品，是一種集成藍牙功能的芯片基本電路集合，用于無線絡通訊。藍牙模塊如同晶振一般，種類奇多。

低功耗藍牙模塊支持藍牙協議4.0或更高的模塊，也稱為BLE模塊，最大的特點是成本和功耗的降低，應用于實時性要求比較高的產品中，比如：智能家居類（藍牙鎖、藍牙燈），消費類電子（電子煙、遙控玩具）等。

MC-146

日本愛普生晶振SG3225CAN是一款支持CMOS輸出的石英晶體振蕩器(SPXO)系列，小體積尺寸3.2x2.5mm有源晶振，四腳貼片晶振，具有超小型，輕薄型，低功耗，低電流消耗特點，1.6V至3.63V的寬工作電壓和寬工作溫度范圍從-40℃到+105℃，這些SPXO提供從2.0x1.6mm到7.0x5.0mm的五種不同封裝尺寸，并提供標準引腳排列。非常適合物聯網、藍牙模塊，便捷式設備，可穿戴設備、醫療、工業自動化等各種應用。

藍牙模塊專用晶振SG3225CAN編碼X1G005961002215

產品編碼 型號 頻率 石英晶振 輸出波 電源電壓 工作溫度
X1G005961000115 SG3225CAN 24.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961000215 SG3225CAN 25.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961000315 SG3225CAN 48.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961000415 SG3225CAN 8.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961000515 SG3225CAN 10.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961000615 SG3225CAN 12.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961000715 SG3225CAN 20.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961000815 SG3225CAN 24.576000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961000915 SG3225CAN 40.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961001015 SG3225CAN 50.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961001115 SG3225CAN 4.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961001215 SG3225CAN 4.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961001315 SG3225CAN 8.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961001415 SG3225CAN 10.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961001515 SG3225CAN 12.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -20 to 70 °C
X1G005961001615 SG3225CAN 12.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961001715 SG3225CAN 12.288000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -20 to 70 °C
X1G005961001815 SG3225CAN 12.288000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961001915 SG3225CAN 12.288000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961002015 SG3225CAN 14.745600MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961002115 SG3225CAN 14.745600MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961002215 SG3225CAN 16.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961002315 SG3225CAN 16.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961002415 SG3225CAN 20.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -20 to 70 °C

SG2016CAN，SG3225CAN,SG5032CAN,SG7050CAN,SG-210STF

X1G005961002515 SG3225CAN 20.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961002615 SG3225CAN 24.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -20 to 70 °C
X1G005961002715 SG3225CAN 24.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961002815 SG3225CAN 24.576000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961002915 SG3225CAN 25.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -20 to 70 °C
X1G005961003015 SG3225CAN 25.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961003115 SG3225CAN 26.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961003215 SG3225CAN 26.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961003315 SG3225CAN 27.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961003415 SG3225CAN 27.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961003515 SG3225CAN 32.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961003615 SG3225CAN 32.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961003715 SG3225CAN 33.330000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961003815 SG3225CAN 33.330000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961003915 SG3225CAN 33.333300MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 85 °C
X1G005961004015 SG3225CAN 33.333300MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961004115 SG3225CAN 40.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961004215 SG3225CAN 48.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -20 to 70 °C
X1G005961004315 SG3225CAN 48.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961004415 SG3225CAN 50.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -20 to 70 °C
X1G005961004515 SG3225CAN 50.000000MHz 3.20x2.50x1.05mm CMOS 1.620 to 3.630 V -40 to 105 °C
X1G005961004615 SG3225CAN 72.000000MHz 3.20x2.50x1.05mm CMOS 1.710 to 3.630 V -20 to 70 °C
X1G005961004715 SG3225CAN 72.000000MHz 3.20x2.50x1.05mm CMOS 1.710 to 3.630 V -40 to 85 °C
X1G005961004815 SG3225CAN 72.000000MHz 3.20x2.50x1.05mm CMOS 2.250 to 3.630 V -40 to 105 °C

藍牙模塊專用晶振SG3225CAN編碼X1G005961002215

藍牙模塊中最佳貼片晶振組合常用到一款MHZ晶振和32.768KHZ晶振，MHZ晶振中常用頻率最為廣泛應用，12MHZ，16MHZ，24MHZ，26MHZ，32MHZ。通常使用到的封裝為2016mm貼片晶振，2520mm貼片晶振，3225mm貼片晶振。
