康納溫菲爾德公司發布Stratum3E標準的14腳OCXO振蕩器

返回列表 來源：金洛鑫 瀏覽：- 發布日期：2024-01-02 08:59:19【大 中 小】
分享到：

康納 溫菲爾德新聞2.1

康納溫菲爾德公司發布Stratum3E標準的14腳OCXO振蕩器，伊利諾伊州奧羅拉，ConnorWinfield晶振公司新推出的OH414針DIP系列OCXO是基于SC切割晶體的振蕩器專門設計用于與<1mH至.1Hz的低濾波器帶寬配合使用，以符合基于T1的層次結構規范，例如ITU-TG.8262選項1和2ECC、ITU-TG.8263、ITU-TG.813選項1和2SEC，用于Sonet、IEEE1588和同步以太網的第3層和3E層。CW的OH4OCXO系列采用小尺寸14x20mm作為SMD或14引腳DIP通孔封裝。

OH4OCXO振蕩器系列配置選項提供10ppb峰峰值頻率穩定性、-40至+85C的工業溫度范圍以及出色的性能，低相位噪聲、短期穩定性和老化特性。

康納 溫菲爾德新聞2.2

康納溫菲爾德公司發布Stratum3E標準的14腳OCXO振蕩器

特征：

•可用頻率范圍從10MHz到100MHz，標準頻率為12.8MHz，19.2MHz、19.44MHz、20MHz、24.576MHz、25MHz、38.88MHz、40MHz和100MHz。
•3.3VLVCMOS或正弦輸出
•固定輸出或電壓控制
•符合在.1Hz帶寬下測量的層級MTIE和TDEV掩模
•10ppb峰峰值溫度穩定性
•在12kHz-20MHz頻段內低于300ps的抖動性能
•使用壽命精度為+/-1ppm
•完全符合ROHS和REACH標準

•14x20mm貼片或通孔封裝選項

原廠代碼 品牌 型號 類型 頻率 輸出 電壓 穩定度 工作溫度
DGOF5S3-020.0M Connor-Winfield DGOF OCXO 20MHz HCMOS, TTL 5V 250ppb 0°C ~ 70°C
DGOF5S3-010.0M Connor-Winfield DGOF OCXO 10MHz HCMOS, TTL 5V 250ppb 0°C ~ 70°C
DOCSC022F-025.0M Connor-Winfield DOCSC OCXO 25MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-025.0M Connor-Winfield DOCSC OCXO 25MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-025.0M Connor-Winfield DOCSC OCXO 25MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH4610LF-040.0M Connor-Winfield OH4 OCXO 40MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH4610LF-025.0M Connor-Winfield OH4 OCXO 25MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH100-61003CF-010.0M Connor-Winfield OH100 OCXO 10MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
BSOF3S3E-010.0M Connor-Winfield BSOF3S3E OCXO 10MHz HCMOS 3.3V ±10ppb 0°C ~ 70°C
ASOF3S3-020.0M Connor-Winfield ASOF3S3 OCXO 20MHz LVCMOS 3.3V 250ppb 0°C ~ 70°C
ASOF3S3-012.8M Connor-Winfield ASOF3S3 OCXO 12.8MHz LVCMOS 3.3V 250ppb 0°C ~ 70°C
OH100-50503CF-010.0M Connor-Winfield OH100 OCXO 10MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH100-50503CF-012.8M Connor-Winfield OH100 OCXO 12.8MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH100-61003CF-020.0M Connor-Winfield OH100 OCXO 20MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
ASOF3S3-010.0M Connor-Winfield ASOF3S3 OCXO 10MHz LVCMOS 3.3V 250ppb 0°C ~ 70°C
OH100-61003CF-012.8M Connor-Winfield OH100 OCXO 12.8MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OX400-620LF-020.0M Connor-Winfield OX400-620LF OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OX400-620LF-024.576M Connor-Winfield OX400-620LF OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH4610LF-38.88M Connor-Winfield OH4 OCXO 38.88MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH100-70503CF-024.576M Connor-Winfield OH100 OCXO 24.576MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH100-70503CF-020.0M Connor-Winfield OH100 OCXO 20MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-70503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-70503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-70503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OHSM100-60803CF-010.0M Connor-Winfield OHSM100-60803CF OCXO 10MHz LVCMOS 3.3V ±8ppm -40°C ~ 85°C
OH200-61003CF-024.576M Connor-Winfield OH200 OCXO 24.576MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
OH100-60503CF-024.576M Connor-Winfield OH100 OCXO 24.576MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
OH200-61003CF-020.0M Connor-Winfield OH200 OCXO 20MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
DOCSC022F-024.576M Connor-Winfield DOCSC OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-024.576M Connor-Winfield DOCSC OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-024.576M Connor-Winfield DOCSC OCXO 24.576MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH200-51003CF-012.8M Connor-Winfield OH200 OCXO 12.8MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH200-51003CF-005.0M Connor-Winfield OH200 OCXO 5MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH100-50503CF-020.0M Connor-Winfield OH100 OCXO 20MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-61003CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-50503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-70503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-70503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-70503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -20°C ~ 70°C
OH300-50503CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-012.8M Connor-Winfield OH300 OCXO 12.8MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-60503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
OH300-60503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
OH300-60503CF-024.576M Connor-Winfield OH300 OCXO 24.576MHz CMOS 3.3V ±5ppb -40°C ~ 85°C
OH300-61003CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-020.0M Connor-Winfield OH300 OCXO 20MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-50503CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-010.0M Connor-Winfield OH300 OCXO 10MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-61003CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±10ppb -20°C ~ 70°C
OH300-61003CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±10ppb -20°C ~ 70°C
OH300-61003CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±10ppb -20°C ~ 70°C
OHSM100-60803CF-020.0M Connor-Winfield OHSM100-60803CF OCXO 20MHz LVCMOS 3.3V ±8ppm -40°C ~ 85°C
DOCSC022F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH4610LF-024.576M Connor-Winfield OH4 OCXO 24.576MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
DOCSC022F-020.0M Connor-Winfield DOCSC OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-020.0M Connor-Winfield DOCSC OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
DOCSC022F-020.0M Connor-Winfield DOCSC OCXO 20MHz LVCMOS 3.3V ±20ppb -40°C ~ 85°C
OH4610LF-012.8M Connor-Winfield OH4 OCXO 12.8MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH4610LF-010.0M Connor-Winfield OH4 OCXO 10MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH4610LF-020.0M Connor-Winfield OH4 OCXO 20MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
ASOF5S3-012.8M Connor-Winfield ASOF5S3 OCXO 12.8MHz HCMOS 5V 250ppb 0°C ~ 70°C
ASOF5S3-019.44M Connor-Winfield ASOF5S3 OCXO 19.44MHz HCMOS 5V 250ppb 0°C ~ 70°C
OH200-51003CF-010.0M Connor-Winfield OH200 OCXO 10MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OFC5DJ3BS-010.0M Connor-Winfield OFC5DJ3BS OCXO 10MHz Sine Wave 5V ±20ppb -20°C ~ 70°C
OFC5DJ3BS-020.0M Connor-Winfield OFC5DJ3BS OCXO 20MHz Sine Wave 5V ±20ppb -20°C ~ 70°C
DOCSC012F-020.0M Connor-Winfield DOCSC OCXO 20MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-50503CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-040.0M Connor-Winfield OH300 OCXO 40MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-61003CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-025.0M Connor-Winfield OH300 OCXO 25MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
DOCSC012F-040.0M Connor-Winfield DOCSC OCXO 40MHz LVCMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-50503CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-50503CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±5ppb 0°C ~ 70°C
OH300-61003CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
OH300-61003CF-050.0M Connor-Winfield OH300 OCXO 50MHz CMOS 3.3V ±10ppb -40°C ~ 85°C
